THE USR2
ENHANCED GLARE CONTROL
The USR2 luminaire provides replacement of up to 2000W HID in a form factor that is smaller and lighter allowing safe and easy retrofit of existing systems. With standard diode level internal glare control, the USR2 provides a vast reduction in on and off field glare that is not available in any other product. Available in 800W, the USR2 is an extremely versatile sports lighter ideal for arenas, sporting complexes and professional stadiums.
PRODUCT FEATURES
» Industry Leading, Diode Level Glare Control
» Dim to Off Technology
» Standard DALI-2 D4i Drivers
» Available 0-10V Dimming
» Controls Ready 24V Auxiliary
» Integral and Remote Driver Operation
» Standard Stainless-Steel Aiming Device
» Designed and Manufactured in Texas, USA
THE USR2: SPORTSLIGHTER
» Superior Glare Control
» Precision Aiming System
» Low-Profile, Heavy-Duty Mounting
» Tool-Less Driver Housing
» Beam Indication Labels
OTHER FEATURES
» Stainless Steel Trunnion
» Glass-Enclosed Optics
» 20kV/10kA UL1449 Surge Protection
» 7-Pin Dimming Receptacle and Wireless Controls Available
» Available with an Integral or Remote Driver
» Available as Part of a Complete UL Listed System from CHM Sports
USR2 FEATURES
GLARE CONTROL
CHM Lighting is the pioneer in offering glare-free, high-powered LED sports lighting solutions. The USR2 offers the latest in internal diode-level glare control by minimizing direct views of the LED optics from all viewing angles. The USR2's glare control is enclosed within the fixture, thereby eliminating degradation and dirt buildup on and around the glare control optics.
STAINLESS STEEL AIMING DEVICE
The standard on every USR2 is that the stainless steel aiming device ensures precision field aiming during installation and when adjustments are needed.
VERTICAL AIMING DIAL
The heavy-duty cast aluminum vertical aiming dial provides a secure, two-bolt clamping system to ensure the fixture does not move out of the set aiming position due to vibration or high winds. The integrally cast aiming dial gives simple and straightforward verification of the down angle on both sides of the luminaire.
HEAVY-DUTY MOUNTING BRACKET
The USR2 comes standard with a heavy-duty cast aluminum mounting bracket that includes integrally cast aiming angle indication. The mounting bracket pushes the trunnion forward to improve clearance and allow proper fanning of the fixtures without interference, which is prevalent in most contemporary LED sports lighting fixtures.
TOOL-LESS DRIVER HOUSING
Unlike most contemporary LED sports lighting luminaires, the USR2 is designed with service in mind. The driver housing features stainless steel draw latches that permit opening without the need for tools or fasteners. The cover is tethered to the driver housing with a stainless steel safety chain, so it can be set aside during service without the fear of dropping parts.
BEAM INDICATION LABELS
A highly visible, color-coded label affixed to the front of the luminaire indicates the optical distribution of the system. This label is visible from the field and allows verification of beam type and location after installation without having to check the actual part number at the fixture location.
